DIPLOMA IN AUTOCAD

Course Syllabus

AUTO CAD 2D

• Introduction to Auto CAD, Co-ordinate Systems
• Practice of Co-ordinates with Line command, Limmax, Erase, Line by
• Direct method
• Direct method
• Drafting Settings, Spline, Revision Cloud, X-line, Ray
• Rectangle, Circle, Polygon, Fillet, Chamfer
• Ellipse, Arc, Polyline, Edit (Practicing commands till date)
• Move, Copy, Offset, Rotate
• Mirror, Trim, Extent
• Array, Scale, Stretch
• Hatch, Linetypes
• Layer, Layer Management
• Dimension
• Text, Editing Text
• Break, Measure, Dived, Lengthen, Area, I.D., D.I., Group, Join
• Design Centre
• Xref, Xclip

AUTOCAD 3D

• Introduction to 3D, Isometric Views
• Thickness, Elevation
• 3D Views, Changing Viewports, Visual Styles, Orbit, Solid Primitives
• Extrude, Revolve
• Loft, Sweep
• Intersect, Subtract, Union, Fillet, Chamfer, Align
• Slice, Roatate3D
• Mirror3D, 3DArray
• Solid Editing
• Rendering
